Product Details
The Compact Pro 60 is a diesel-powered spraying machine built for large exterior rendering and plastering jobs. Made in France by Euromair, it combines an integrated 200 litre mixer and a 240 litre hopper with a MAP 11 pump, so renders, mortars and hydraulic coatings can be mixed and sprayed on site without a separate mixer or mains power.
Trailer mounted and easily towed between sites, it runs on an 18 kW Kohler diesel engine with an on-board compressor, delivering a variable flow of up to 60 litres per minute at up to 40 bar. Ideal for large wall jobs, hydraulic coatings, mortars and external wall insulation (EWI) systems.
TECHNICAL CHARACTERISTICS
Motor Kohler LDW 1003 diesel, 18 kW (Stage V)
Fuel tank 25 L (approx. 3.1 L/h consumption)
Compressor flow rate 400 L/min at 4 bar
Mixer tank capacity 200 L
Hopper capacity 240 L
Loading height 86 cm
Product flow rate 0 to 60 L/min
Max. pressure 0 to 40 bar
Max. grain size 6 mm
Pump MAP 11
Max. hose length 60 m
Delivery height 50 m
Dimensions (L x W x H) 358 x 150 x 128 cm (with tow bar)
Weight 750 kg (full)
Noise level 101 dB(A)
Download the Compact Pro 60 datasheet (PDF)
Download the Compact Pro 60 user manual (PDF)
Product images are for reference only and the actual make/model may vary.
Have a question or not sure if this is suitable for your project? Ask the grout pump equipment experts at Grout Pump Hire on 0409295833.
| Optional Extras | Extra Grout Hoses, Wet Hire |
|---|
